The WHO Testing Cage for Arm-in-Cage (AIC) Bioassay Studies is designed for evaluating the repellency, attraction, and behavioral responses of mosquitoes and other flying insects under controlled laboratory conditions. The cage features a clear acrylic observation chamber, arm access sleeve, mirror-assisted landing observation system, and a modular aluminum profile frame for easy assembly and dismantling. Available in multiple sizes, the cage is ideal for repellent efficacy studies, attraction assays, and vector behavior research following WHO-recommended testing methodologies
Construction Details
| Component | Material / Description |
|---|---|
| Top Panel | Clear Acrylic (Fully Removable) |
| Front Panel | Clear Acrylic with 20 cm Sleeve Opening and Nylon Sleeve |
| Left Side | Clear Acrylic |
| Right Side | White Nylon Mesh |
| Back Side | White Nylon Mesh |
| Bottom Panel | White Acrylic Base |
| Observation System | Removable Mirror Placement on Bottom |
| Frame Material | Modular Aluminum Profile |
| Assembly Type | Interlocking Modular Design |
| Installation | Tool-Free Assembly & Dismantling |
Compatible Bioassay Equipment
The following related bioassay equipment is also available:
- WHO Cone Test Kit
- WHO Bottle Assay Kit
- WHO Susceptibility Tube Assay Kit
- Mosquito Holding Cages
- Mosquito Release Cages
- Y-Tube Olfactometers
- Dual Choice Olfactometers
- Vector Behavior Testing Systems
Available Models
| Model | Internal Dimensions |
|---|---|
| LI-Cage-01 | 30 × 30 × 30 cm |
| LI-Cage-02 | 45 × 45 × 45 cm |
| LI-Cage-03 | 60 × 60 × 60 cm |
The WHO Testing Cage for Arm-in-Cage (AIC) Bioassay Studies is a specialized research cage developed for mosquito repellency testing, attraction studies, and behavioral bioassays involving direct exposure of treated or untreated human skin.
The cage provides a controlled environment where mosquitoes can be observed while interacting with test subjects or chemical treatments. The design allows researchers to monitor landing, attraction, feeding behavior, and repellency responses during experimental trials.
The cage incorporates a unique combination of clear acrylic observation panels and fine nylon mesh ventilation panels, providing excellent visibility while maintaining adequate airflow for insect survival and natural behavior.
The front panel features a 20 cm diameter sleeve opening that allows comfortable insertion of the forearm during testing procedures. The bottom section includes a white acrylic base with a removable mirror, enabling researchers to observe mosquitoes landing beneath the arm without disturbing the test.
For routine cleaning and maintenance, the entire top section is removable, allowing easy access to all internal surfaces. This feature helps prevent contamination between experiments and supports proper laboratory hygiene.
Constructed using modular aluminum profiles with interlocking assembly edges, the cage can be easily assembled, dismantled, transported, and stored. The modular design makes it suitable for laboratories, research institutions, universities, and field research facilities.
The cage is supplied in knock-down (KD) form with assembly instructions, enabling quick installation without specialized tools.
Key Features
✓ WHO-style Arm-in-Cage (AIC) bioassay design
✓ Suitable for repellency and attraction studies
✓ Large 20 cm arm access sleeve opening
✓ Mirror-assisted observation of mosquito landings
✓ Clear acrylic viewing panels for unobstructed observation
✓ White nylon mesh ventilation panels
✓ Fully removable top panel for easy cleaning
✓ Modular aluminum profile construction
✓ Interlocking assembly system
✓ Easy installation and dismantling
✓ Lightweight yet durable structure
✓ Supplied in knock-down form for convenient transport
Applications
- Mosquito Repellency Studies
- Arm-in-Cage (AIC) Bioassays
- Attractant Evaluation
- Vector Behavior Research
- Insect Landing Studies
- Product Efficacy Testing
- Public Health Entomology
- Vector Control Research
- Academic and University Research
- WHO-Based Mosquito Bioassays
The WHO Testing Cage for Arm-in-Cage Bioassay Studies provides researchers with a practical and reliable platform for evaluating mosquito repellents, attractants, and host-seeking behavior. Its modular aluminum construction, clear observation panels, removable top section, and mirror-assisted viewing system make it an ideal choice for laboratories conducting standardized mosquito behavioral studies and product efficacy evaluations.
